8.4” display, networking and GPS chartplotter performance features, including newly-expanded built-in background map of the U.S. and Europe. Waterproof memory card slots are compatible with a superb variety of high-detail, plug-&-play electronic chart options loaded on MMC/SD cards.
GlobalMap® 8200C GPS Chartplotter
DISPLAY
- Display Size
- 8.4 in 213 mm
- Display Resolution
- 600 x 800 (H x W)
- Display Type
- 16-bit color full VGA SolarMax™ TFT
- Backlighting
- Screen/Keypad
- Backlighting Type
- Cold cathode
- Resize Display Window
- Yes
- GPS Overlay Data
- Yes
- Split Screen Presentation
- Yes
- Multilanguage Display
- Yes
GPS / NAVIGATION
- GPS Antenna Type
- External GPS+WAAS
- GPS Receiver Channels
- 12 channels
- Background Map
- Built-in enhanced background map of the US and Hawaii
- Custom Mapping
Optional MapCreate™ USA Topo Accessory Pack, FreedomMaps™, Fishing Hot Spots® PRO, LakeMaster® ProMaps, NauticPath™, and Navionics®
- Man Overboard Feature
- Yes
- GPS Alarms
- Yes
NETWORKING / CONNECTORS
- NMEA 0183 Input
- Yes
- NMEA 2000 Pending Certification
- Yes
- NMEA Output
- 0183/2000
TECHNICAL / ENVIRONMENTAL
- Built-in Backup Memory
- Yes
- Casing
- Sealed and waterproof
- Width
- 10.6 in 269 mm
- Height
- 7.8 in 198 mm
- Depth
- 3.7 in 94 mm
POWER
- Power Supply
- 10 - 17 vDC
OTHER
- Memory Card Capable
- Two MMC/SD memory card slots
- Other Features
5-pin Ethernet expansion port and two full RS-232 port
