Ocean Signal ATB1 AIS Transceiver Class B+ SOTDMA With WIFI and External Antenna
What is SOTDMA or CLASS B+ ? Down load this white paper prepared by Digital Yacht that explains all.
We have also put together our own overview of the Ocean Signal ATB1 and what Class B+ is all about:
Features of the Ocean Signal ATB1
- Increased visibility to other vessels (SOTDMA)
- FREE user-friendly mobile app for set up
- WiFi, USB, NMEA 0183 and NMEA 2000® connectivity
- Simple to install and use
- Superior internal 99 channel GPS receiver
- Supplied with GPS antenna
The fully compliant Ocean Signal ATB1 Class B AIS Transponder from Ocean Signal is the latest in a long line of essential sea-safety equipment developed and manufactured in the UK for the Maritime market. Designed as an aid to collision-avoidance, it provides a significant advantage in navigational safety giving you the peace of mind that your vessel will be seen day or night, no matter the weather, on today’s busy waterways.
Your vessel information such as position, speed, course and heading is ascertained automatically and continuously using the impressive internal multi-GPS receiver for accurate global positioning. Boasting 99 acquisition channels and 33 tracking channels, this advanced technology ensures that the AIS transmissions provide the most accurate indication of your vessel’s position at all times.
Other vessel information such as vessel name, call sign, type and dimensions as well as the MMSI are also transmitted automatically from the ATB1. This information is uploaded to the Ocean signal ATB1 via WiFi directly from Ocean Signal’s user-friendly mobile app or website. Once this information has been uploaded, it remains stored in the unit’s nonvolatile memory even if powered down for long periods of time.
The Ocean Signal ATB1 also receives and interprets AIS messages from other AIS equipped vessels within range, which can then be relayed effortlessly to other navigation devices such as chart plotters, laptops or mobiles using the ATB1’s NMEA 0183, NMEA 2000®, USB or WiFi outputs.
Using the superior SOTDMA access scheme sets the ATB1 apart from the CSTDMA class B products available. This Ocean Signal Class B unit has the same AIS transmission priority as a class A unit, giving the added assurance that there will be no loss or delay of transmission, even in high-traffic areas.
The Ocean Signal ATB1 also has a faster reporting rate and higher output power than CSTDMA class B units. It sends AIS transmissions every 5 seconds instead of the maximum two transmissions per minute and the 5W output power instead of 2W allows your transmissions to reach further.
A multi-colour LED indicator light on the ATB1 signals the on-going operational status of the unit. This additional safety feature provides you the confidence of knowing that the ATB1 has continuous AIS transmission and optimal performance.
The Ocean Signal ATB1 has a sleek yet rugged waterproof design that is high on performance and low on energy consumption. It is quick and simple to install and comes complete with an external GPS
antenna, meaning that all you need is the use of a suitable device (mobile phone, tablet or PC) to upload your vessel information, and you can begin transmitting your AIS messages within minutes.
A leader in life-saving maritime products for the professional and leisure markets, Ocean Signal yet again provides the ultimate in safety and peace of mind with the ATB1 Class B Transponder.
- Ocean Signal AIS Config - Available on IOS and Android - You cab use this APP to configure your AIS, enter your MMSI number and boat details as well as switch on and off alarms and silent mode.
- NV-Charts - Available on Android - A great way to display AIS targets on a basic MAP, you can download more detailed cartography via the in-app purchase.
- Seanav - Available on IOS - Another great navigation APP which is AIS compatible.
AIS Transponder Comparison Table:
Using the set up app
For Apple OS
For PC or Laptop
